Rear Differential Assembly for JAC HFC1063

This rear differential assembly is offered for JAC HFC1063 truck application enquiries. Use the rear-axle identification and original differential configuration when selecting the replacement.

Include the crown-wheel and pinion tooth counts, axle-shaft spline count, input flange and mounting dimensions. Photographs of the axle plate and assembly provide useful matching details.

Send the vehicle and axle identification, crown-wheel and pinion tooth counts, spline details and quantity. Include the flange and housing dimensions for the assembly required.

Contact TOSEN for a quotation or browse Differential Assemblies.

The rear differential assembly for the JAC HFC1063 is the final-drive component of the light truck’s rear axle, where the driveline completes its reduction and the torque is shared between the two driving wheels. Rotation from the propeller shaft meets the pinion at the input flange, transfers to the crown wheel at a right angle and reaches the side gears that drive the axle shafts, and those gears permit speed differences between the shafts during turns so the rear wheels roll the different distances a corner demands. In goods work, the assembly is the point where engine output finally becomes hauling force at the road.

• Component: rear differential assembly for the JAC HFC1063
• Vehicle application: JAC HFC1063 light truck
• Location: rear axle, between the propeller shaft and the axle shafts
• Duty: final reduction, torque split and wheel-speed compensation under load

The rear differential assembly for the JAC HFC1063 is matched to the truck through the rear-axle identification, supported by photographs of the axle plate and the assembly being replaced. The details that decide the match are the crown-wheel and pinion tooth counts, the axle-shaft spline count, the input flange and the mounting dimensions, all taken from the original unit. Trucks in circulation can differ in axle specification according to build and service history, so the figure set from the vehicle itself takes priority over any description based on the model name alone. Once the measurements and pictures reach TOSEN, the enquiry is matched against the correct assembly before a quotation is issued.

• Identification basis: rear-axle identification plus axle-plate photographs
• Figures to supply: crown-wheel and pinion tooth counts, axle-shaft spline count
• Dimensions to supply: input flange and mounting dimensions
• Priority rule: measurements from the vehicle outrank the model name

Each rear differential assembly for the JAC HFC1063 is supplied new by TOSEN and inspected against the axle details in the enquiry. The verification compares the tooth counts, the spline count and the flange and mounting dimensions with the figures the customer supplies, and photographs sent with the enquiry serve as the reference for the check. Operators running several HFC1063 trucks can have each vehicle processed individually, so the delivered assemblies are matched to each axle rather than picked from one assumed specification for the whole fleet.

What is the rear differential assembly for the JAC HFC1063?

The rear differential assembly for the JAC HFC1063 is the assembled final-drive unit of the light truck’s rear axle, housing the pinion, the crown wheel and the side gears in one component. Drive entering at the input flange is reduced by the gear pair and divided between the two axle shafts, and the shafts can rotate at unequal speeds around corners because of the side-gear arrangement. The assembly replaces the worn original as a complete part.

How is the right HFC1063 differential assembly confirmed?

Confirm the rear-axle identification first, then record the crown-wheel and pinion tooth counts, the axle-shaft spline count, the input-flange details and the mounting dimensions from the old assembly. Photograph the axle plate and the removed unit and send everything with the enquiry. TOSEN matches those details to the assembly before quoting, so the replacement fits the axle on the truck instead of a generic HFC1063 description.

Why do axle-plate photographs matter for this truck?

The axle plate carries the identification of the specific rear axle fitted to the truck, which is the detail that separates one axle specification from another within the same model line. A photograph preserves the full stamping without transcription errors and shows features a written list may omit. Combined with the tooth counts and spline details, the plate picture lets the correct rear differential assembly be selected on the first order.

What should an HFC1063 enquiry include?

Provide the vehicle identification, the rear-axle identification from the axle plate, the crown-wheel and pinion tooth counts, the axle-shaft spline count, the input-flange and mounting dimensions, the quantity and the destination. Attach photographs of the axle plate and the assembly being replaced, and TOSEN will confirm the matching rear differential assembly and quote it.
