The 33030-0W641 Toyota Hiace gearbox is a five-speed manual transmission assembly fitted to the 2.8-litre 3L diesel Hiace and several related Toyota vans and pickups. It is also listed under the numbers 33030-26691 and 33030-0L010, which makes buying one confusing when different sellers use different codes. This guide shows you how to confirm that a 33030-0W641 gearbox matches your vehicle, which numbers interchange with it, how to plan for oil and seals, and what to check before and after the gearbox is shipped.
Is the Same 33030 Number Used Across Every Hiace?
The short answer is no. Toyota stamped similar-looking numbers on several gearbox variants, and the same number family does not automatically fit every Hiace from every year. The 33030-0W641 assembly is a manual transmission built for the Hiace III box (body codes such as YH7_, LH6_, LH7_, LH5_, YH5_, YH6_) with the 2.4-litre 2RZ petrol or the 2.8-litre 3L diesel, and for later Hiace vans and commuters in the LH172 and LH184 range. A workshop that only looks at the model name “Hiace” and skips the body code can order the wrong unit.
The reliable way to match a gearbox is to line up three facts: the OEM number on the old transmission label, the body code stamped on the vehicle plate, and the full VIN. Toyota’s own parts catalogue treats these three together, because body code, drive layout and market decide the exact variant. That is why a supplier that asks for the VIN before quoting is following the correct process rather than adding friction.
There is also a common mix-up you should know about. When people search for a Hiace gearbox they often land on pages about the JATCO JF011E, which is a continuously variable transmission used in Nissan, Mitsubishi and Chrysler vehicles. The JF011E has nothing to do with the 33030-0W641 manual unit, but both names appear in transmission forums and shop articles. ATSG’s published transmission service material on the JF011E family is useful if you work on those CVTs, but it is the wrong reference for a Toyota manual gearbox — confirming the OEM number and the vehicle record is the only safe filter.
You can see the exact unit we supply for this fitment on our High-Quality Gearbox for Toyota Hiace 3L/5L – OEM Part No. 33030-0W641/33030-26691/33030-0L010 page, which lists the Hiace 3L/5L application and the supplied configuration.
OEM Cross-Reference: Which Numbers Interchange with 33030-0W641?
Buyers see at least four numbers for this gearbox family: 33030-0W641, 33030-26691, 33030-0L010, and sometimes 33030-2F160 or 33030-0K260. These are Toyota OE numbers for the same manual transmission family, and parts suppliers list them together because they are the most common alternates found in the catalogue. That does not mean every one of them is a drop-in swap for every chassis, but it means a seller who lists all three is working from the same OE cross-reference.
Use the cross-reference as a starting point, not as proof. Two rules keep you safe. First, check the drive layout: a 2WD Hiace and a 4WD Hiace use different gearbox housings, output flanges and tail housings even when the model name is identical. Second, check the hand-drive layout: RHD and LHD vans can carry different cables, levers and brackets. The input shaft, bellhousing pattern and output flange all have to match the engine, the clutch, and the rear drive layout of the exact vehicle.
The practical move is to photograph the gearbox data plate or the old-part label, write down the VIN, and send both to the supplier. A supplier with the catalogue in front of them can tell you whether 33030-0W641, 33030-26691 or 33030-0L010 is the right alternate for your vehicle before a crate is built. This is where a cross-reference becomes useful instead of risky.
Gearbox Oil, Seals and Clutch: What a Fresh 33030-0W641 Needs
A bare gearbox assembly usually arrives without gearbox oil, and often without a new clutch kit. Plan for three consumables before the box goes near the vehicle: the correct manual transmission oil for the Hiace application, a new input shaft seal and output seal where they are not already fitted, and the clutch disc, pressure plate and release bearing that transfer from your old setup or come as a separate kit.
Oil choice matters more than most buyers expect. A manual box that was filled with the wrong viscosity will whine, shift hard in cold weather, or run hot under load. Check the vehicle manual or the oil spec on the old gearbox and match the fill to the application. If the gearbox has been sitting in a warehouse, also check the seal condition before installation — a dry seal can leak once the box is filled and run.
For a complete picture of what is available for this vehicle and others, browse our manual and automatic transmissions category, which covers the transmission types we supply across the Hiace range and other makes.
New or Remanufactured Hiace Gearbox: How to Verify What You Buy
Two condition options dominate the market: brand-new units and remanufactured units that start from a used core. Both can be perfectly usable, and both can be badly sold, so the label matters less than the verification. For a new gearbox, ask what is included, whether seals and bearings are fresh, and whether the unit is test-shifted before it leaves the factory. For a remanufactured box, ask what was actually replaced — bearings, synchronizer rings and seals wear first — and whether the core return policy is clear.
Core return is a decision point many importers forget. If you buy a reman unit, the supplier may charge a core deposit and ask you to send your old gearbox back. Confirm the condition the core must be in, who pays the return freight, and how long the deposit takes to release. Written answers protect both sides and stop a surprise charge from appearing after the job is done.
The same buying logic applies across gearbox types, so if you are still deciding between a manual and an automatic for a fleet, our related technical guide compares both options for cost, downtime and driver training before you commit.
Crate Size, Sea Freight and the Arrival Inspection Checklist
For an importer, the crate is part of the product. A manual gearbox is heavy and its castings crack if the crate is dropped or stacked badly, so ask for the crate dimensions and gross weight before you book freight. Typical units of this family ship at roughly 30–35 kg gross in a crate around 60 × 40 × 25 cm, but the number varies by packaging and accessories — request the exact figure for your order rather than assuming. That figure drives your sea-freight quote, so getting it early saves a re-quote.
When the crate arrives, run the same checklist every time. Photograph the crate before you open it, while the carrier is still present. Look for impact damage, crushed corners or water stains. Check the gearbox against the packing list: part number, casting marks and any label should match the order. Check the input shaft and output flange for dents, the case for cracks, and the vent and plugs for missing parts. If anything is damaged, photograph it and report it to the supplier and the carrier before you sign the delivery note.
Installation Steps After the Gearbox Arrives
Once the box passes inspection, installation is a controlled sequence. Check the clutch flywheel face and pilot bearing first — a worn flywheel can wreck a good gearbox in the first week. Fit the new input shaft seal and clutch release bearing, torque the pressure plate to the clutch spec, then hang the gearbox on the engine and check the bellhousing alignment before you tighten everything down.
Fill the gearbox with the correct oil before the first start, bleed and adjust the clutch as required for the vehicle, and verify the shifter linkage returns to neutral cleanly in every gear. Then road-test through every gear under light load before loading the van. A five-minute test catches most install errors while they are cheap to fix.
After the first run, check for drips under the bellhousing and at the output seal. A small leak at this stage usually means a seal was pinched during install — easier to correct now than after the vehicle goes back to work. Keep the gearbox number, the oil spec and the install date with the invoice so the warranty and the maintenance record start from a clean line.
Frequently Asked Questions
Does a 33030-0W641 gearbox fit any Toyota Hiace 3L?
It fits the Hiace III and related vans with the 3L diesel and 2RZ petrol in the correct body-code range. Confirm the body code, drive layout and VIN with the supplier, because the same model name covers different gearbox variants.
Are 33030-26691 and 33030-0L010 the same as 33030-0W641?
They are Toyota OE alternates in the same manual transmission family. They are commonly interchangeable, but the input shaft, output flange and drive layout must be checked against your exact vehicle before ordering.
Should I buy a new or a remanufactured 33030-0W641 gearbox?
Both can be sound. For new units, check what is included and whether it is test-shifted. For reman units, ask which parts were replaced and confirm the core-return policy, including freight and deposit terms, in writing.
What oil does a 33030-0W641 gearbox take?
Use the manual transmission oil specified for the Hiace application in the vehicle manual. Never guess the viscosity — the wrong oil causes noise, hard shifting and overheating.
Do I need to buy a clutch kit with the gearbox?
A bare gearbox usually ships without clutch components. Plan for a clutch disc, pressure plate, release bearing and input/output seals, and inspect the flywheel before installation.
Get a Fitment-Confirmed Quote
Submit your VIN, old-part label / OE number, model year, quantity, and destination port to receive a fitment confirmation and a quote. This closes the loop: the same identifiers that prove the gearbox matches your Hiace become the records used to ship the correct 33030-0W641 unit — or its verified alternate — in a crate sized for your freight route.
